| Name: | DA 15672 | |
| Title: | State plan with excavation sections and grid lines. | |
| Artist: | James Herbst | |
| Notes: | Version of PD 1210. It's designed to be printed in color, 100% size on to A0 paper (84.1cm x 118.9cm) then trimmed down from there to about 68.1cm x 81.4cm plus margins. The final scale will then be 1:750. | |
| Scale: | 1:750 | |
| Date: | 15 Aug 2025 |
|
